Inconel Pipes & Tubes Manufacturer, Supplier & Exporter
Vivid Steel & Engineering Co. Ltd. is one of India’s trusted manufacturers, suppliers, stockists and exporters of premium-quality seamless, welded, fabricated or custom-sized Inconel Pipes & Tubes designed for demanding industrial environments. Vivid Steel & Engineering Co. Ltd. manufactures Inconel Pipes & Tubes using advanced production techniques, precision machinery and stringent quality control processes. Every product undergoes comprehensive testing to ensure compliance with international standards before dispatch. Our products comply with ASTM, ASME, DIN, EN, ISO and international manufacturing standards, ensuring dimensional accuracy, excellent surface finish and outstanding performance.
Get a Quote for Inconel Pipes & Tubes
- Immediate Quotation
- Mill Test Certificate (EN 10204 3.1)
- Third Party Inspection
- Fast Delivery Worldwide
- Custom Sizes Available
Product Specifications
| Product Name | Inconel Pipes & Tubes |
| Manufacturer | Vivid Steel & Engineering Co. Ltd. |
| Material | Nickel-Chromium Superalloy |
| Grades | 600, 601, 617, 625, 686, 690, 718, 725, X-750, 800, 800H, 800HT, 825 |
| Forms | Seamless, Welded, Fabricated |
| Pipe Size | 1/8″ NB to 48″ NB |
| Tube Size | 6 mm OD to 219 mm OD |
| Wall Thickness | SCH 5S to SCH XXS |
| Length | Single Random, Double Random, Cut Length |
| Ends | Plain End, Bevel End, Threaded |
| Surface Finish | Pickled, Annealed, Bright Annealed, Polished |
| Standards | ASTM, ASME, DIN, EN, ISO |
| Testing | PMI, Hydro Test, UT, ET, IGC, Hardness, Mechanical Tests |
| Documentation | MTC EN 10204 3.1 / 3.2, NABL Reports, Third Party Inspection |
| Packaging | Wooden Boxes, Bundles, Export Packing |
INCONEL PIPES & TUBES – PRODUCT OVERVIEW
Inconel is a family of high-performance nickel-chromium alloys specifically developed to withstand aggressive environments where conventional stainless steels fail. The addition of chromium, molybdenum, niobium, titanium and other alloying elements provides exceptional resistance against oxidation, carburization, pitting, crevice corrosion and stress corrosion cracking.
Top Manufacturers, Suppliers, Dealers of Inconel Pipes, Best Prices for Inconel Pipes in Mumbai. Our Inconel Pipes and Tubes offer excellent mechanical strength, remarkable creep resistance, superior fatigue performance and long service life under extreme operating conditions. These properties make them an ideal choice for chemical processing, offshore oil & gas, aerospace, marine engineering, power generation, heat exchangers, nuclear plants, pollution control systems and petrochemical industries.
| Grade | Ni | Cr | Fe | Mo | Nb+Ta | Co | Al | Ti | Cu |
|---|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 72.0 Min | 14.0–17.0 | 6.0–10.0 | — | — | — | — | — | 0.50 Max |
| Inconel 601 | 58.0–63.0 | 21.0–25.0 | Balance | — | — | — | 1.0–1.7 | — | 1.0 Max |
| Inconel 617 | Balance | 20.0–24.0 | 3.0 Max | 8.0–10.0 | — | 10.0–15.0 | 0.8–1.5 | 0.6 Max | 0.5 Max |
| Inconel 625 | 58.0 Min | 20.0–23.0 | 5.0 Max | 8.0–10.0 | 3.15–4.15 | 1.0 Max | 0.40 Max | 0.40 Max | — |
| Inconel 686 | Balance | 19.0–23.0 | 2.0 Max | 15.0–17.0 | — | — | — | 0.25 Max | — |
| Inconel 690 | 58.0 Min | 27.0–31.0 | 7.0–11.0 | — | — | — | — | — | 0.50 Max |
| Inconel 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.50 | 1.0 Max | 0.2–0.8 | 0.65–1.15 | 0.30 Max |
| Inconel X-750 | 70.0 Min | 14.0–17.0 | 5.0–9.0 | — | 0.7–1.2 | 1.0 Max | 0.4–1.0 | 2.25–2.75 | 0.50 Max |
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB Max) |
| Inconel 600 | 550 | 240 | 30 | 195 |
| Inconel 601 | 550 | 205 | 30 | 220 |
| Inconel 617 | 680 | 310 | 35 | 240 |
| Inconel 625 | 827 | 414 | 30 | 220 |
| Inconel 686 | 827 | 414 | 40 | 230 |
| Inconel 690 | 586 | 241 | 30 | 220 |
| Inconel 718 | 965 | 550 | 30 | 330 |
| Inconel X-750 | 930 | 620 | 20 | 350 |
| Property | Typical Value |
| Density | 8.19–8.47 g/cm³ |
| Melting Range | 1260–1400°C |
| Modulus of Elasticity | 200–214 GPa |
| Electrical Resistivity | 1.03–1.30 µΩ·m |
| Thermal Conductivity | 9–15 W/m·K |
| Specific Heat | 420–460 J/kg·K |
| Magnetic Permeability | Essentially Non-Magnetic (Annealed) |
| Coefficient of Thermal Expansion | 12–15 µm/m·°C |
OUR RANGE OF INCONEL PIPES & TUBES
Inconel Seamless Pipes
Inconel Welded Pipe
Inconel ERW Pipes
Inconel Square Tubes
Inconel Hydraulic Tubes
Inconel Condenser Tubes
Inconel Heat Exchanger T
Inconel Boiler Tubes
Inconel Instrumentation Tubes
Key Features
- Exceptional corrosion resistance
- Excellent oxidation resistance
- Outstanding strength at elevated temperatures
- High pressure resistance
- Superior fatigue resistance
- Excellent weldability
- Long service life
- High creep rupture strength
- Excellent mechanical properties
- Resistant to chloride environments
- Suitable for cryogenic temperatures
- Easy fabrication
- High dimensional accuracy
- Smooth internal surface
- Leak-proof performance
Available Grades
- Inconel 600 Pipes
- Inconel 601 Pipes
- Inconel 617 Pipes
- Inconel 625 Pipes
- Inconel 686 Pipes
- Inconel 690 Pipes
- Inconel 718 Pipes
- Inconel 725 Pipes
- Inconel X-750 Pipes
- Incoloy 800 Pipes
- Incoloy 800H Pipes
- Incoloy 800HT Pipes
- Incoloy 825 Pipes
Inconel Seamless Pipes
Seamless Inconel pipes are manufactured without any welded joints, providing superior strength, higher pressure handling capability and exceptional corrosion resistance. These pipes are preferred in critical applications such as refineries, offshore platforms, aerospace systems and high-pressure process plants.
Advantages
- Uniform wall thickness
- Better pressure handling
- Excellent structural integrity
- Reduced leakage risk
- Longer service life
- Ideal for high-temperature applications
Inconel Welded Pipes
Welded Inconel pipes are manufactured by rolling alloy plates followed by precision welding. They offer an economical solution for medium to large diameter applications while maintaining excellent corrosion resistance and dimensional accuracy.
Benefits
- Cost-effective
- Available in larger diameters
- Excellent finish
- Faster production
- Easy customization
- Suitable for structural applications
Seamless vs Welded Inconel Pipes
| Feature | Seamless | Welded |
|---|---|---|
| Manufacturing | Extruded | Plate Rolled & Welded |
| Strength | Higher | High |
| Pressure Rating | Excellent | Very Good |
| Corrosion Resistance | Excellent | Excellent |
| Cost | Higher | Economical |
| Large Diameter Availability | Limited | Excellent |
| Surface Finish | Excellent | Excellent |
| Critical Applications | Preferred | Suitable |
Standard Dimensions
Vivid Steel & Engineering Co. Ltd. supplies Inconel Pipes & Tubes in standard as well as custom dimensions to meet project-specific requirements.
Pipe Dimensions
| Parameter | Range |
| Nominal Bore | 1/8″ NB to 48″ NB |
| Outside Diameter | 10.3 mm to 1219 mm |
| Wall Thickness | SCH 5S to SCH XXS |
| Pipe Length | Up to 12 Meters |
| End Finish | Plain, Bevelled, Threaded |
| Manufacturing | Seamless / Welded / ERW / EFW |
Tube Dimensions
| Parameter | Range |
| Outside Diameter | 6 mm to 219 mm |
| Wall Thickness | 0.5 mm to 20 mm |
| Length | Up to 12 Meters |
| Surface Finish | Bright Annealed, Pickled, Polished |
| Shape | Round, Square, Rectangular |
Approximate Pipe Weight Chart
Approximate Weight per Meter
| Nominal Size | SCH 10S (kg/m) | SCH 40S (kg/m) | SCH 80S (kg/m) |
| 1/2″ | 0.85 | 1.27 | 1.62 |
| 3/4″ | 1.13 | 1.69 | 2.20 |
| 1″ | 1.68 | 2.50 | 3.24 |
| 1½” | 2.72 | 4.05 | 5.41 |
| 2″ | 3.65 | 5.44 | 7.28 |
| 3″ | 5.44 | 8.10 | 11.29 |
| 4″ | 7.24 | 10.79 | 15.07 |
| 6″ | 10.90 | 18.97 | 28.26 |
| 8″ | 14.50 | 28.55 | 42.45 |
Inspection & Testing
Applications of Inconel Pipes & Tubes
| INDUSTRY | APPLICATION |
| Oil & Gas Industry | * Offshore drilling platforms * Subsea pipelines * Flowlines * Refineries * LNG terminals * Gas processing plants * Wellhead equipment * Heat exchangers * Pressure vessels |
| Petrochemical Industry | * Reactor systems * Process piping * Distillation columns * Furnace tubes * Transfer lines * Chemical reactors * Storage systems |
| Chemical Processing Industry | * Acid production plants * Alkali processing * Fertilizer plants * Chlorination units * Sulfuric acid plants * Nitric acid processing * Pharmaceutical manufacturing |
| Aerospace Industry | * Aircraft exhaust systems * Jet engines * Combustion chambers * Turbine components * Hydraulic tubing * Fuel delivery systems |
| Marine Industry | * Shipbuilding * Naval vessels * Offshore platforms * Seawater cooling systems * Marine condensers * Saltwater piping |
| Power Generation | * Boilers * Superheaters * Heat exchangers * Steam generators * Nuclear reactors * Gas turbines * Waste heat recovery systems |
| Additional Industries Served | * Desalination Plants * Food Processing Industry * Pharmaceutical Industry * Paper & Pulp Industry * Sugar Plants * Cement Industry * Mining Industry * Defence Sector * Renewable Energy Plants * Water Treatment Plants * Semiconductor Manufacturing * Automotive Industry |
International Standards
Vivid Steel & Engineering Co. Ltd. manufactures and supplies Inconel Pipes & Tubes in accordance with globally recognized standards to ensure product quality, dimensional accuracy, and reliable performance.
- ASTM B167
- ASTM B517
- ASTM B444
- ASTM B705
- ASTM B775
- ASTM B829
- ASME SB167
- ASME SB517
- ASME SB444
- ASME SB705
- EN Standards
- DIN Standards
- ISO Standards
- ANSI Standards
- MSS Standards
- NACE MR0175 / ISO 15156 (where applicable)
Why Buy Inconel 625 Pipes & Tubes from Vivid Steel & Engineering Co. Ltd.?
Wide Product Range
Inconel seamless pipes
Inconel welded pipes
Inconel seamless tubes
Inconel welded tubes
Inconel Heat exchanger tubes
Inconel Instrumentation tubes
Inconel Precision tubes
International Specifications
NABL-approved Testing
Mill Test Certificates (EN 10204 3.1 / 3.2)
ISO-compliant Experienced technical team
Third-party inspection support
Commercially Competitive Supply
Competitive Pricing Fast domestic and international deliveries
Export-worthy Packaging. Full Customer Support
